STANDARD 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
19′ 4″ | 7′ 8″ | 7′ 10″ | 7′ 8″ | 7′ 6″ | 1,172 Cf t | 4,916 Lbs | 47,900 Lbs |
5.900 m | 2.350 m | 2.393 m | 2.342 m | 2.280 m | 33.2 Cu.m | 2,230 Kgs | 21,770 Kgs |
STANDARD 40′ | |||||||
39′ 5″ | 7′ 8″ | 7′ 10″ | 7′ 8″ | 7′ 6″ | 2,390 Cf t | 8,160 Lbs | 59,040 Lbs |
12.036 m | 2.350 m | 2.392 m | 2.340 m | 2.280 m | 67.7 Cu.m | 3,700 Kgs | 26,780 Kgs |
UPGRADED 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
19′ 4″ | 7′ 7″ | 7′ 10″ | 7′ 6″ | 7′ 6″ | 1,150 Cf t | 5,060 Lbs | 61,996 Lbs |
5.900 m | 2.311 m | 2.390 m | 2.286 m | 2.280 m | 32.63 Cu.m | 2,300 Kgs | 28,180 Kgs |
HIGH CUBE 40′ | |||||||
39′ 5″ | 7′ 8″ | 8′ 10″ | 7′ 8″ | 8′ 5″ | 2,694 Cf t | 8,750 Lbs | 58,450 Lbs |
12.036 m | 2.350 m | 2.697 m | 2.338 m | 2.585 m | 76.3 Cu.m | 3,970 Kgs | 26,510 Kgs |
REEFER 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
17′ 8″ | 7′ 5″ | 7′ 5″ | 7′ 5″ | 7′ 3″ | 1,000 Cf t | 7,040 Lbs | 45,760 Lbs |
5.425 m | 2.275 m | 2.260 m | 2.258 m | 2.216 m | 28.3 Cu.m | 3,200 Kgs | 20,800 Kgs |
REEFER 40′ | |||||||
37′ 8″ | 7′ 5″ | 7′ 2″ | 7′ 5″ | 7′ 0″ | 2,040 Cf t | 10,780 Lbs | 56,276 Lbs |
11.493 m | 2.270 m | 2.197 m | 2.282 m | 2.155 m | 57.8 Cu.m | 4,900 Kgs | 25,580 Kgs |
REEFER 40′ HIGH CUBE | |||||||
37′ 11″ | 7′ 6″ | 8′ 2″ | 7′ 6″ | 8′ 0″ | 2,344 Cf t | 9,900 Lbs | 57,561 Lbs |
11.557 m | 2.294 m | 2.500 m | 2.294 m | 2.440 m | 66.6 Cu.m | 4,500 Kgs | 25,980 Kgs |
OPEN TOP 20′(Upgradable also available) | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
19′ 4″ | 7′ 7″ | 7′ 8″ | 7′ 6″ | 7′ 2″ | 1,136 Cf t | 5,280 Lbs | 47,620 Lbs |
5.894 m | 2.311 m | 2.354 m | 2.286 m | 2.184 m | 32.23 Cu.m | 2,400 Kgs | 21,600 Kgs |
OPEN TOP 40′ | |||||||
39′ 5″ | 7′ 8″ | 7′ 8″ | 7′ 8″ | 7′ 5″ | 2,350 Cf t | 8,490 Lbs | 58,710 Lbs |
12.028 m | 2.350 m | 2.345 m | 2.341 m | 2.274 m | 65.5 Cu.m | 3,850 Kgs | 26,630 Kgs |
FLAT RACK 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
18′ 5″ | 7′ 3″ | 7′ 4″ | 5,578 Lbs | 47,333 Lbs | |||
5.620 m | 2.200 m | 2.233 m | 2,530 Kgs | 21,470 Kgs | |||
FLAT RACK 40′ | |||||||
39′ 7″ | 6′ 10″ | 6′ 5″ | 12,081 Lbs | 85,800 Lbs | |||
12.080 m | 2.438 m | 2.103 m | 5,480 Kgs | 39,000 Kgs |
FLAT RACK COLLAPSIBLE 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
18′ 6″ | 7′ 3″ | 7′ 4″ | 6,061 Lbs | 61,117 Lbs | |||
5.618 m | 2.208 m | 2.233 m | 2,750 Kgs | 27,730 Kgs | |||
FLAT RACK COLLAPSIBLE 40′ (Stak Bed) | |||||||
39′ 7″ | 6′ 10″ | 6′ 5″ | 12,787 Lbs | 85,800 Lbs | |||
12.080 m | 2.126 m | 2.043 m | 5,800 Kgs | 39,000 Kgs |
PLATFORM 20′ | |||||||
Inside Length | Inside Width | Inside Height | Door Width | Door Height | Capacity | Tare Weight | Maxi Cargo |
---|---|---|---|---|---|---|---|
19′ 11″ | 8′ 00″ | 7′ 4″ | 6,061 Lbs | 52,896 Lbs | |||
6.058 m | 2.438 m | 2.233 m | 2,750 Kgs | 24,000 Kgs | |||
PLATFORM 40′ | |||||||
40′ 00″ | 8′ 00″ | 6′ 5″ | 12,783 Lbs | 89,397 Lbs | |||
12.18 m | 2.40 m | 1.95 m | 5,800 Kgs | 39,200 Kgs |
